The Asus ROG Swift PG32UCDM monitor is a powerful display designed for gamers and content creators who demand the best in visual performance.
To help you get the most out of this monitor, we’ve compiled a comprehensive guide to optimize its settings for gaming, movies, and general use.
Follow these steps to enhance your viewing experience and enjoy the full capabilities of your PG32UCDM monitor.
Table of Contents
Here are the Best Color Settings for the Asus ROG Swift PG32UCDM Monitor:
Optimizing Gaming Settings
Variable Refresh Rate
For a smooth gaming experience, enable the variable refresh rate. This feature helps eliminate screen tearing and stuttering. However, if you notice any flickering, particularly in darker scenes, consider disabling this setting to maintain visual stability.
Extreme Low Motion Blur (ELMB)
The ELMB feature can only be used when the input is set to 120 Hz. Since the PG32UCDM is a 240 Hz monitor, this setting is less than ideal for most uses. If your system can’t handle 4K at 240 Hz, you might drop down to 120 Hz and enable ELMB for improved motion clarity. Keep in mind that this will reduce brightness significantly.
Game Plus Features
The Game Plus section offers useful tools such as frame rate counters and crosshairs. These can be helpful for certain games, so feel free to use them as needed.
Shadow Boost
This setting enhances visibility in dark scenes by brightening shadows. While it can be useful, it also raises the black levels, which might affect overall picture quality. Experiment with this setting based on the specific games you’re playing and your ambient lighting conditions.
Game Visual Mode
Switch the Game Visual mode to “User” to unlock full control over all settings, including RGB adjustments for calibration.
Adjusting Image and Color Settings
Settings for SDR Content
When viewing standard dynamic range (SDR) content, you have two primary options:
- sRGB Gamut: This setting is ideal for SDR accuracy. It ensures colors are displayed as intended, without oversaturation.
- Native Wide Gamut: Choose this if you prefer more vivid and saturated colors, which can enhance gaming and movie experiences.
sRGB Mode
- Color Space: Set to sRGB.
- Color Temperature: Default (6500K).
- Gamma: Default (2.2).
- Uniform Brightness: Enable to maintain consistent brightness across different content.
- Brightness: Adjust to 42 for 120 nits, 55 for 150 nits, or 75 for 200 nits. The maximum brightness is 265 nits at 100%.
Wide Gamut Mode
- Color Space: Set to Wide.
- Color Temperature: User setting. Adjust RGB values to Red: 98, Green: 100, Blue: 100 for a white point close to 6500K.
- Gamma: Default (2.2).
- Uniform Brightness: Enable this feature.
- Brightness: Same adjustment range as in sRGB mode.
For users who want precise color calibration, consider using a calibrated ICC profile that can clamp the wide gamut back to sRGB in color-aware applications like Photoshop.
Settings for HDR Content
When viewing high dynamic range (HDR) content, several specific settings come into play:
- HDR Mode: Choose between Console, Movie, Gaming, or True Black. The Gaming mode is generally recommended for its balance of brightness and detail.
- Brightness Cap: The HDR 400 True Black mode caps brightness at around 470 nits, which might be restrictive for some HDR content. Experiment with the other modes to find what works best for you.
Only enable HDR mode when viewing HDR content, such as HDR games or movies, to avoid unnecessary strain on the display and potential dimming in non-HDR tasks.
System Settings and OLED Care
USB-C Charging
By default, USB-C charging is set to 65 watts. If you need 90 watts, be aware that it will limit the maximum brightness to 180 nits. Leave it at 65 watts unless higher power is necessary.
Proximity Sensor
Enable the proximity sensor to turn off the screen when you’re not in front of it. This feature helps reduce power consumption and extends the life of the OLED panel.
OLED Care Options
These options can be managed through the onscreen menu or the Asus Display Widget Center Software:
- Logo Brightness: Dims static elements like logos to prevent burn-in.
- Pixel Cleaning Cycle: Run this cycle manually or let it prompt you periodically for maintenance.
- Screen Saver: Dims the screen when it detects inactivity or static content.
- Screen Move: Shifts pixels periodically to reduce the risk of image retention. If this is distracting, adjust the setting to a lower level or turn it off.
Conclusion
By following these settings, you can ensure that your Asus ROG Swift PG32UCDM monitor delivers optimal performance for both SDR and HDR content. Adjust the brightness and color settings according to your personal preferences and room conditions to achieve the best visual experience possible. Enjoy your enhanced viewing and gaming sessions with your finely tuned monitor!
